Korg NAUTILUS 88 User Manual

Detailed Combination editing Effects
69
Effects
Effects are covered in their own section of the manuals, so
we won’t go into too much detail here.
Insert Effects
Insert Effects let you send either individual Oscillators or the
entire Program through up to 12 effects, in series. You can
use any type of effects, from distortions and compressors to
choruses and reverbs. The Insert Effects can be routed to the
main outputs, or to any of the individual outputs.
For more information, see “Insert effects” on page 223.
Master Effects
There are two Master Effects, which are accessed through
Sends 1 and 2. These are best-suited to effects such as
reverbs and delays, but you can use them with any type of
effect.
For more information, see “Master effects” on page 224.
Total Effects
The two Total Effects are dedicated to processing the main
L/R outputs. They’re ideally suited to overall mix effects,
such as compression, limiting, and EQ–but as with the other
effects sections, you can use any type of effect that you like.

Korg NAUTILUS 88 Specifications

General

MIDI	In, Out, Thru
Keyboard	88-key RH3 (Real Weighted Hammer Action 3)
Sound Engines	9 sound engines
Effects	12 insert effects, 2 master effects
Display	8-inch (800 x 480 pixels) TouchView display
Sequencer	16-track MIDI sequencer
Sampling	Open Sampling System
User Memory	Approx. 60 GB SSD
External Storage	USB Flash Drive
Controllers	Joystick
Audio Outputs	L/MONO, R
Audio Inputs	L/MONO, R (1/4" jacks)
USB	Type A
Pedal Inputs	Damper, Assignable
Weight	23.1 kg / 50.93 lbs
Dimensions	1, 437 x 387 x 139 mm / 56.57" x 15.24" x 5.47"
Power Supply	AC adapter (included)
