Reference Guide
104
6A–6D MIDI Filter
These parameters allow you to control how the X5 will handle MIDI data.
Timbres 1–8 Timbres 1–8 Timbres 1–8 Timbres 1–8
6A Program Change Filter:
These parameters determine how EXT mode Timbres work with MIDI
Program Change messages.
Enable:
With this setting, received Program Change messages select Programs for a Timbre.
Use 2C MIDI FILTER PRG in Global mode to set the global X5DR Program Change filter. (see
2C Program Change Filter on page 152.)
6B Damper Pedal Filter:
These parameters determine how Timbres respond to damper pedal
message.
Enable:
With this setting, Timbres respond to damper pedal messages.
Disable:
With this setting, damper pedal messages are ignored.
6C After Touch Filter:
These parameters determine how Timbres respond to After Touch messages.
Enable:
With this setting, Timbres respond to After Touch messages.
Disable:
With this setting, After Touch message is ignored.
6D Control Change Filter:
These parameters determine whether Timbres respond to MIDI
Controllers.
Enable:
With this setting, Timbres respond to controllers.
Disable:
With this setting, controllers are ignored.
LCD Parameter Range Description
6A Timbre 1~8 Program Change Filter
D: Disable
E: Enable
Program Change messages ignored
Program Change messages can be received and sent
6B Timbre 1~8 Damper Pedal Filter
D: Disable
E: Enable
Timbre will ignore the damper pedal
Timbre will respond to the damper pedal
6C Timbre 1~8 After Touch Filter
D: Disable
E: Enable
Timbre will ignore After Touch
Timbre will respond to After Touch
6D Timbre 1~8 Control Change Filter
D: Disable
E: Enable
Timbre will ignore controllers
Timbre will respond to controllers
Note:
If the Global mode 2C MIDI Program Change Filter1 is set to DIS (“2C MIDI FILTER
PRG” on page 152), Program Change messages are completely disabled. This setting overrides
the above settings. Furthermore, if the channel that matches Global mode MIDI Program Change
Filter1 is set to ENA, Program Change messages received on the Global MIDI Channel will
select Combinations. With the PRG setting, Combinations are not changed. Only the Programs
that have Timbres with the same channel settings are changed.
06A PROG CHANGEø
EEDDEEEE
6A
6B
06B DAMPER ø
EEEEEEEE
6C
06C AFTER TOUCHø
EEEEEEEE
6D
06D CONTROL CHG
EEEEEEEE
ø
