Reference Guide
117
Reference Guide
Effect
Parameters
4
VDA EG: 64 voices, which is the sum of all the VDA EG levels. This is very effective when you
play chords. (“n” is a MIDI channel.)
To control dynamic modulation via MIDI, set the MIDI transmit channel of the control source
(such as the X3) will that of the Global MIDI Channel.
Dynamic Modulation Intensity:
The dynamic modulation intensity can be set from –15 to +15.
Positive values cause dynamic modulation to increase the value of the effect parameter being
controlled. Negative values have the opposite effect.
17A–17D Effect1 Parameters
Effect parameters are explained in detail from page 120 onwards.
18A–18C Effect2 Setup
These parameters are used to set up Effect2. Operation is the same as for “16A–16C Effect1
Setup” on page 116.
19A–19D Effect2 Parameters
Effect parameters are explained in detail from page 120 onwards.
20A–20B Effect Placement
The X5DR effect processors can be used in any one of four placements. Placements affect the way
in which the four input buses (A, B, C, D) are routed through the effects.
The Panpot, Send C Level, and Send D Level parameters are set as part of an individual Program,
Combination, or Multi setup.
Page 20B appears when you select Serial, Parallel 1, or Parallel 2 for 20A Placement. Here, you
can set the L/R output balance for Pan 3 and Pan 4. Page 20B' appears when you select Parallel 3
for the placement. In this case, Pan 3 and Pan 4 are replaced by four independent level controls.
The X5DR has two outputs (L/MONO, R).
LCD Parameter Range Description
20A Effect Placement
Serial (Serial)
Parallel 1 (Parallel)
Parallel 2 (Paralel2)
Parallel 3 (Paralel3)
Effect routing configurations
20B
Panpot 3
OFF
L
99:1–1:99
R
No signal output
Signal is panned hard left
Panned between L and R (50:50 pan center)
Signal is panned hard right
(this LCD screen appears when Serial, Parallel 1, or
Parallel 2 is selected)
Panpot 4
20B’
Level 1L (L)
0–9
Set the output level of each effect when Parallel 3 is
selected.
(this LCD is available only when Parallel 3 placement is
selected)
Level 1R (R)
Level 2L (L)
Level 2R (R)
20A PLACEMENTXXø
Serial
20B EFF2XPANPOTX
3=XXLXXX4=XXR
20B E1/E2XLEVELX
L=5XR=5XL=5XR=5
20A
20B 20B’
ø
ø
