Kramer VS-211XS User Manual

Kramer Electronics Ltd.
VS-211XS, VS-411XS – Protocol 3000
70
Protocol 3000 Commands
Function
Description
Syntax
Parameters/Attributes
Example
#
Protocol
handshaking.
Validates the
Protocol 3000
connection and gets
the machine number.
Step-in master
products use this
command to identify
the availability of a
device.
COMMAND
#<CR>
FEEDBACK
~nn@ok<CR><LF>
#<CR>
AUD-EMB?
Get audio in video
embedding status.
COMMAND
#AUD-EMB?in_index,out_index<CR>
FEEDBACK
~nn@AUD-EMBin_index,out_index,emb_mode<CR><LF>
in_index – Number that indicates the
specific input:
1-4 (or 1-2)
out_index – Number that indicates the
specific output:
1
emb_mode – Embedding status
0 – Analog
1 – Embedded
2 – Auto
Get audio embedded
status of input 1:
#AUD-
EMB?1,1<CR>
AUD-LVL
Set volume level.
COMMAND
#AUD-LVLio_mode,io_index,vol_level<CR>
FEEDBACK
~nn@AUD-LVLio_mode,io_index,vol_level<CR><LF>
io_mode –
1 – Output
io_index – 1
vol_level – Volume level -96.0db to
12.0dB;
++ (increase current value by 0.5dB);
-- (decrease current value by 0.5dB)
Set AUDIO OUT
level to -50.0dB:
#AUD-LVL1,1,-
50.0<CR>
AUD-LVL?
Get volume level.
COMMAND
#AUD-LVL?io_mode,io_index<CR>
FEEDBACK
~nn@AUD-LVLio_mode,io_index,vol_level<CR><LF>
io_mode –
1 – Output
io_index – 1
vol_level – Volume level -96.0db to
12.0dB;
Get AUDIO OUT
level:
#AUD-
LVL?1,1<CR>
AUD-LVL-
RANGE?
Get volume level min
and max range.
COMMAND
#AUD-LVL-RANGE?io_mode,io_index<CR>
FEEDBACK
~nn@AUD-LVL-
RANGEio_mode,io_index,min_val,max_val<CR><LF>
io_mode –
1 – Output
io_index – 1
min_val – -96.0db
max_val – 12.0dB
Get AUDIO OUT
level range:
#AUD-LVL-
RANGE?1,1<CR>
AUD-ONLY?
Get audio-only mode
status
COMMAND
#AUD-ONLY?io_mode<CR>
FEEDBACK
~nn@AUD-ONLYio_mode,status<CR><LF>
io_mode –
1 – Output
status – On/Off
0 – Off
1 – On
Get audio-only
status:
#AUD-ONLY?1<CR>
AUD-SIGNAL?
Get audio input
signal status.
COMMAND
#AUD-SIGNAL?in_index<CR>
FEEDBACK
~nn@AUD-SIGNALin_index,status<CR><LF>
in_index – Number that indicates the
specific input:
1-N (N= the total number of inputs)
status – On/Off
0 – Off (no signal)
1 – On (signal present)
Get the status of
input 1:
#AUD-
SIGNAL?1<CR>
AUD-SIG-TYPE
Get audio-only mode
status
COMMAND
#AUD-SIG-TYPEio_mode,io_index,signal_type<CR>
FEEDBACK
~nn@AUD-SIG-TYPEio_mode,io_index,signal_type<CR><LF>
io_mode –
0 – Input
1 – Output
io_index –
Number that indicates the specific input:
1-N (N= the total number of inputs)
signal_type – On/Off
0 – AES
1 – Analog
2 – ARC
Set audio output
signal type to ARC:
#AUD-SIG-
TYPE1,1,2<CR>
AUD-SIG-TYPE?
Get audio-only mode
status
COMMAND
#AUD-SIG-TYPE?io_mode,io_index<CR>
FEEDBACK
~nn@AUD-SIG-TYPEio_mode,io_index,signal_type<CR><LF>
io_mode –
0 – Input
1 – Output
io_index –
Number that indicates the specific input:
1-N (N= the total number of inputs)
signal_type – On/Off
0 – AES
1 – Analog
2 – ARC
Get audio output
signal type:
#AUD-SIG-
TYPE?1,1<CR>
AV-SW-MODE?
Get input auto switch
mode (per output).
COMMAND
#AV-SW-MODE?layer_type,out_index<CR>
FEEDBACK
~nn@AV-SW-MODElayer_type,out_index,connection_mode<CR><L
F>
layer_type – Number that indicates
the signal type:
1 – Video
2 – Audio
out_index – 1
connection_mode – Connection mode
0 – manual
1 – priority switch
2 – last connected switch
Get the input audio
switch mode for
HDMI OUT:
#AV-SW-
MODE?1,1<CR>
AV-SW-TIMEOUT
Set auto switching
timeout.
COMMAND
#AV-SW-TIMEOUTswitching_mode,time_out<CR>
FEEDBACK
~nn@AV-SW-TIMEOUTswitching_mode,time_out<CR><LF>
switching_mode – Switching mode
0 – Video signal lost
4 – Disable 5V on video output if no
input signal detected
5 – Video cable unplugged
time_out – Timeout in seconds
0 - 60000
Set the auto
switching timeout to 5
seconds in the event
of 5V disable when
no input signal is
detected:
#AV-SW-TIMEOUT4
,5<CR>
