Kramer VS-211XS User Manual

Kramer Electronics Ltd.
VS-211XS, VS-411XS – Technical Specifications
62
Default Communication Parameters
RS-232
Baud Rate:
115,200
Data Bits:
8
Stop Bits:
1
Parity:
None
Command Format:
ASCII
#ROUTE 1,1,2<CR>
#ROUTE 1,1,2<CR>
IP (DHCP set to ON)
Fallback IP Address:
192.168.1.39
Fallback Subnet Mask:
255.255.255.0
Fallback Gateway:
192.168.1.1
UDP Port #:
50000
TCP Port #:
5000
User/Password:
Admin/Admin
Full Factory Reset
Web pages
Device Settings > General Settings > Factory reset
This resets device parameters to their factory default values, excluding IP
parameters
RESET button
Press briefly to restart the device.
Press and hold (5 seconds) to fully reset the device parameters to their
default values, including IP parameters.
Default Automation settings
Ports List
Port Name
Type
Port Properties
Port Description
Comments
WOL-Echo
WOL
7
WOL-Discard
WOL
9
Internal
Internal
Enabling actions on the device
itself, such as switching an
input.
CEC-TV
CEC
0
Enabling actions such as display
on/off.
CEC-Broadcast
CEC
15
Non-Serial-on-GW
TCP
192.168.1.40,
5000
Gateway Non-
serial ports
For example, Relay, GPIO and
IR control on the FC-28
gateway (optional, purchased
separately).
Actions List
Action Name
Commands List
On Port
Comments
GW-IO1-Config
#GPIO-CFG 1,1,1,0
Non-Serial-on-
GW
GPIO 1 => Blinds up/down
GW-IO1-Setup
#GPIO-STATE 1,0
GPIO1 initialize
GW-IO2-Config
#GPIO-CFG 2,1,1,0
GPIO 2 => For future use
GW-IO2-Setup
#GPIO-STATE 2,0
GPIO2 initialize
GW-Relay1-Setup
#RELAY-STATE 1,0
Relay 1 => Screen up/down
GW-Relay2-Setup
#RELAY-STATE 2,0
Relay 2 => For user
