VS-211XS, VS-411XS – Technical Specifications
63
Action Name
Commands List
On Port
Comments
GW-Serial1-Setup
#UART 1,9600,8,0,1
Optional display control (in
addition to CEC)
GW-Serial2-Setup
#UART 2,9600,8,0,1
Extra serial control
Switch-IN1
#ROUTE 1,1,1\x0D
Device-internal
Switch-IN2
#ROUTE 1,1,2\x0D
Switch-IN3
#ROUTE 1,1,3\x0D
VS-411XS only
Switch-IN4
#ROUTE 1,1,4\x0D
VS-411XS only
V-Out-Mute
#VMUTE 1,1\x0D
Display sleep
V-Out-Unmute
#VMUTE 1,0\x0D
Display wake-up
A-Out-Volume-Up
#AUD-LVL 1,1,++\x0D
Audio output port action
A-Out-Volume-Down
#AUD-LVL 1,1,--\x0D
A-Out-Mute
#MUTE 1,1\x0D
A-Out-Unmute
#MUTE 1,0\x0D
Screen-Up
#RELAY-STATE 1,0
Non-Serial-on-
GW
Screen-Down
#RELAY-STATE 1,1
Blinds-Up
#GPIO-STATE 1,0
Blinds-Down
#GPIO-STATE 1,1
CEC-Power-On
0x04
CEC-TV
CEC-Power-Off
0x36
CEC-Broadcast
Notify-Restart
#ALERT
ERROR,’Device has
restarted’
Local serial port,
Kramer Network
TCP/UDP port
Notify-MeetingStart
#ALERT OK,’Meeting
has started’
Notify-MeetingEnd
#ALERT OK,’Meeting
has ended’
Notify-PresentationStart
#ALERT
OK,’Presentation
has started’
Notify-PresentationPause
#ALERT
OK,’Presentation
paused’
Notify-
PresentationResume
#ALERT
OK,’Presentation
resumed’
Notify-PresentationEnd
#ALERT
OK,’Presentation
has ended’
Notify-CleaningStart
#ALERT OK,’Room
cleaning has
started’
Notify-CleaningEnd
#ALERT OK,’Room
cleaning has ended’
