krispol STARCUS K06 - Page 28

28
3
1
8
11
13*
7
5
2
6
9
12
or
10
4
START / STOP
1 - rail
2 - drive head
3 - drawbar
4 - carriage handle
5 - fastener for fixing the draw bar to a panel
6 - fastener for fixing the drive to the rail
7 - rail mounting element
8
9
10
11
12
13
*
- a fastener for fixing the rail to the lintel
- unlocking string
- transmitter
- minor elements
- rail lock
- rail suspension
- option
EN
