WARNING - risk of entrapment of a child staying close to a moving garage door.
Keep children away from the moving garage door.
5. Structure of the drive
5.1. Technical data
5.2. Construction of the drive and its components
NOTE! e product can be operated only after the installation process is fully
completed which should be ended by a full final inspection - see sec. 7.1.
Technical data of STARCUS Drive
Parameter Unit
Drive
K06 K10
Type - e drive for the automation of garage doors
Power supply 230VAC (+10%) 50Hz
Electric motor
Maximum input power W 150
Power consumption A 0,7
Pulling power N 600 1000
Lighting - LED
Lighting working time s 180
Emitted sound pressure level dB(A) max 70
Permissible ambient temperature °C -20 to +50
Relative humidity % ≤ 90
Frequency of the receiver MHz 433,92
e maximum distance from the ceiling mm 1000
Normal speed without load cm/s 16
Maximum frequency of cycles % DE 40%
Maximum continuous working time s 60
Protection level IP
Technical data of the transmitter
Parameter Unit Transmitter
Type - 3-channel transmitter, remotely
Frequency MHz 433,92
Coding - Variable code system
Buttons szt. 4
Diode
Power supply V 3
Battery type - 2x CR2016
Capacity mAh 220
Permissible ambient temperature °C -20 to +50
e drive is equipped with:
• control board,
• gear motor,
• a push-button panel with display,
• LED lighting.
e set includes - p. 26
