Operation

Pos: 4.34 /BA/Bedi enung /Run dballenpresse/Folie nbindung/Z um Vergleich zur F olienbindung hier die Netzbind ung @ 325\ mod_142563 7674318_78.doc x @ 250043 3 @ @ 1

For comparison, you can see a figure here as to how the net is inserted.

Pos: 4.35 /Bei packs/Rundball enpressen/Folienbi ndung/Modulg ruppen Folie ei nlegen / LED Lic htleiste/Bildüb erschrift + ZBBP 1932_2: Folie einlegen @ 468\mod_14 69793020845_7 8.docx @ 31616 04 @ @ 1

Path of net:

ZBBP1932_3

Fig.

Pos: 4.36 /BA/Bedi enung /Run dballenpresse/Folie nbindung/Z usatzinfo_oberer K onus bei Netz bindung_Co mprima @ 470\ mod_14714 39953309_78.d ocx @ 3176981 @ @ 1

During net tying, the eyelet bolt (1) must be hooked in at the upper cone (2) in the

support/holder on the clamping lever.

The dimension Y=55 mm is set at the factory.

The locking pin with the knob (3) must be unlocked.
