8.3 Swivelling parking support into transport position
Pos: 21.19 /BA/Bedienung /EasyCut/Abstellstütze/Achtung Abstellstütze eingeklappt EC 280/320 CV-Q @ 10\mod_1221637532743_78.docx @ 135563 @ @ 1
Caution! - Parking support(s) not swivelled into transport position before road/transport
travel and for work!
Effect: Damage to the machine
• Make certain before road/transport travel and for work that the parking support(s) is/are
raised or folded in and secured in place with a bolt!
Pos: 21.20 /BA/Bedienung /EasyCut/Abstellstütze/Abstellstütze angehoben Bild EC 280/320 @ 10\mod_1221638211056_78.docx @ 135648 @ @ 1
EC-161-0
1
2
Figure
15
Pos: 21.21 /BA/Bedienung /EasyCut/Abstellstütze/Abstellstütze angehoben @ 10\mod_1221638250775_78.docx @ 135670 @ @ 1
Lift the parking support (2) into the working position of the disc mower and lock it in place with
the bolt (1).
