KHF - SERIES A FAN COIL UNITS
INSTALLATION, OPERATION, AND MAINTENANCE MANUAL
SERVICE AND CLEARANCE REQUIREMENTS: HEIGHT RESTRICTED APPLICATION
CORNER PANELS
SHOWN ROTATED 90°
UNIT
INSTALLED
0" CLEARANCE BETWEEN UNIT AND STRUCTURE
FULLY
OPENED
CORNER PANELS ROTATED 90°
CAN BE LIFTED AND REMOVED
11" (279) MINIMUM REQUIRED
CLEARANCE BESIDE UNIT
HALF
OPENED
CORNER PANELS ROTATE
ABOUT PIVOT POINT
4" (102) MINIMUM REQUIRED
CLEARANCE BELOW UNIT
0" REQUIRED CLEARANCE
ABOVE UNIT
HORIZONTAL, LOW PROFILE EXPOSED UNITS
