KHF - SERIES A FAN COIL UNITS
INSTALLATION, OPERATION, AND MAINTENANCE MANUAL
TABLE 3: EC MOTORS
UNIT SIZE FAN SPEED
EC MOTOR HP
(QTY)
# OF FANS
WATTS
2
(STD/HS)
AMPS
1,3
115 VOLTS 208/230 VOLTS 277 VOLTS
3-SPEED
(STD/HS)
2-10VDC
3-SPEED
(STD/HS)
2-10VDC
3-SPEED
(STD/HS)
2-10VDC
02
High
(1) 1/4 1
32 / 45
0.7 / 1.0 0.9 0.5 / 0.6 0.5 0.4 / 0.5 0.5Medium 21 / 36
Low 14 / 26
03
High
(1) 1/4 1
35 / 59
1.0 / 1.5 1.1 0.6 / 0.9 0.7 0.5 / 0.8 0.6Medium 23 / 43
Low 16 / 33
04
High
(1) 1/4 2
50 / 75
1.5 / 1.8 1.2 0.9 / 1.1 0.8 0.8 / 0.9 0.6Medium 33 / 56
Low 21 / 41
06
High
(1) 1/4 2
104 / 132
2.6 / 3.1 2.0 1.6 / 1.9 1.2 1.3 / 1.6 1.0Medium 62 / 89
Low 36 / 62
08
High
(1) 1/4 2
91 / 122
2.3 / 2.9 2.0 1.4 / 1.7 1.2 1.2 / 1.5 1.0Medium 54 / 90
Low 31 / 62
09
High
(1) 1/4 2
119 / 182
3.7 / 4.5 2.7 2.3 / 2.7 1.6 1.9 / 2.3 1.4Medium 72 / 116
Low 39 / 77
10
High
(2) 1/4 4
142 / 207
3.9 / 5.1 3.1 2.3 / 3.1 1.9 2.0 / 2.6 1.6Medium 91 / 139
Low 54 / 104
12
High
(2) 1/4 4
143 / 209
3.2 / 4.5 3.5 2.0 / 2.7 2.1 1.6 / 2.3 1.8Medium 92 / 152
Low 56 / 105
NOTES:
1. Motor electrical data is nameplate data.
2. Watts are based on an KHFP with 3-speed EC motor, 3 row coil, 12FPI, 1” throwaway filter, 0.05” ESP at 115V.
3. For neutral conductor sizing, multiply AMPS by 1.73.
4. Motor data is subject to change and should not be used for submittal. Refer to unit submittal for actual ratings.
MOTOR AND FAN DATA
