KSB Guard - Unit Control Elements and LEDs

4 Description
17 of 50
KSB Guard
4079.83/01-EN
5 Level LEDs for indicating the signal
strength of the KSBGuardGateway
connection
6 Earthing connection
7 Connection for the connecting
cable to the sensor unit
Table9: Description/ function of control elements and LED indicators
Control element/ LED indicator Description
Pushbutton Commissioning, status check, manual measurement
Status LED A Status LEDs for indicating the operating status and for coded output of fault
messages
Status LED B
Level LEDs Signal strength of KSBGuardGateway connection
