8 Dismantling
36 of 50
KSB Guard
4079.83/01-EN
8 Dismantling
WARNING
Incorrect dismantling
Crushing, impact injuries, cuts!
▷ Use suitable tools only.
▷ Wear suitable protective equipment.
8.1 Removing KSBGuardGateway
DANGER
Risk of falling when working at a great height
Danger to life by falling from a great height!
▷ Do not step onto the pump (set) during installation work or dismantling work.
▷ Pay attention to safety equipment, such as railings, covers, barriers, etc.
▷ Observe the applicable local health and occupational safety regulations and
accident prevention regulations.
DANGER
Improper work on electrical connection
Electric shock!
▷ KSBGuardGateway may only be opened by a qualified electrical technician.
▷ Electrical work may only be carried out by a qualified electrical technician.
1. Disconnect the equipment from the power supply.
2. Detach the rear adapter of KSBGuardGateway from the wall bracket.
3. Remove the wall-mounting bracket from the wall.
8.2 Dismantling the transmission and battery unit
WARNING
Work in the immediate vicinity of rotating parts
Risk of hand injury!
▷ Always have this work performed by trained personnel.
▷ Take particular caution when performing this work.
WARNING
Hot surfaces (pump and piping take on the temperature of the fluid handled).
Risk of burns!
▷ Do not touch hot surfaces.
1. Disconnect the connecting cable of the sensor unit.
2. Remove the Transmission and battery unit from the place of installation. To
remove the adhesive pad from the pump set, slide a thin wire underneath the
Transmission and battery unit or use a lever tool.
