6 Operation
31 of 50
KSB Guard
4079.83/01-EN
6 Operation
6.1 Operating modes of transmission and battery unit
▪ Deep Sleep
The transmission and battery unit is delivered in Deep Sleep mode. The device is
in this mode prior to commissioning, after it is switched off, and if the battery is
removed for more than 10seconds. (ðSection6.2,Page31)
▪ Set-up mode
The Set-up mode helps find a suitable position for the transmission and battery
unit.
▪ Automatic Measuring Operation
After successful commissioning and when a sensor unit and pump set have been
assigned in the KSB Cloud, the device automatically switches to Stand-by mode
following each measuring cycle and transfer cycle in order to save energy. In this
status, all LEDs are off. The device wakes up cyclically (default setting: every
hour) and takes an automatic measurement.
6.2 Checking that the transmission and battery unit is in Deep Sleep mode
1. Briefly press the pushbutton.
ð The red LED briefly flashes once (for approx. 0.2seconds) in this operating
mode. The red LED then has to extinguish immediately and no further LED
must light up. (ðSection6.1,Page31)
6.3 Taking manual measurement and displaying signal strength
WARNING
Hot surfaces (pump and piping take on the temperature of the fluid handled).
Risk of burns!
▷ Do not touch hot surfaces.
WARNING
Sensor unit takes on temperature of bearing bracket or drive lantern
Risk of burns!
▷ Observe the operating manual of the pump set.
▷ When the pump set is being operated, only touch the sensor unit using suitable
protective gloves.
WARNING
Work in the immediate vicinity of rotating parts
Risk of hand injury!
▷ Always have this work performed by trained personnel.
▷ Take particular caution when performing this work.
ü Commissioning was completed successfully.
1. Briefly press the pushbutton at the Transmission and battery unit once
(<1second).
ð The current status of the device is displayed. The green LED flashes when the
device is ready for a manual event. If this is not the case, the device is busy
(with an automatic measurement, update, etc).
2. When the device is ready for a manual event, once again briefly press the
pushbutton at the Transmission and battery unit.
