3 Transport/Storage/Disposal
13 of 80
HPK
1121.8/06-EN
3 Transport/Storage/Disposal
3.1 Transport
DANGER
The pump (set) could slip out of the suspension arrangement
Danger to life from falling parts!
▷ Always transport the pump (set) in the specified position.
▷ Never attach the suspension arrangement to the free shaft end or the motor
eyebolt.
▷ Observe the information about weights, centre of gravity and fastening points.
▷ Observe the applicable local accident prevention regulations.
▷ Use suitable, permitted lifting accessories, e.g. self-tightening lifting tongs.
To transport the pump/pump set or back pull-out unit suspend it from the lifting
tackle as shown.
Fig.1: Transporting the back pull-out unit
Fig.2: Transporting the pump
Fig.3: Transporting the pump set
