5 Installation at Site
29 of 80
HPK
1121.8/06-EN
Pump model HPK-EY/SY
Table12: Forces and moments at the pump nozzles
Sizes
Suction nozzle
[N]
Discharge nozzle
[N]
Suction nozzle
[Nm]
Discharge nozzle
[Nm]
F
x
F
y
F
z
F
res
F
x
F
yTens
+ F
yCompr
- F
z
F
res
M
x
M
y
M
z
M
x
M
y
M
z
80-400 4900 3200 3900 5100 2300 1400 2850 1900 3000 3600 2700 1850 1900 1450 1000
100-400 4900 3200 3900 5100 2850 1800 3600 2300 3700 3600 2700 1850 2650 2000 1350
125-400 6200 4100 5000 6450 3900 2450 4900 3200 5000 4600 3550 2350 3600 2700 1850
150-315
150-400
9800 6200 7600 9800 5000 3100 6200 4100 6450 7000 5100 3500 4600 3500 2300
200-250 9800 6200 7600 9800 7600 4700 9800 6200 9800 7000 5100 3500 7000 5100 3500
200-315
200-400
200-500
13300 8900 10700 13900 7600 4700 9800 6200 9800 10000 7600 4900 7000 5100 3500
250-315
250-400
250-500
16000 10700 13300 17100 10700 6700 13300 8900 13900 12200 9200 6000 10000 7600 4900
300-400
300-500
17800 11600 14200 18300 13300 8200 16000 10700 17100 12700 9500 6200 12200 9200 6000
350-400
350-500
17800 11600 14200 18300 14200 8900 17800 11600 18400 12700 9500 6200 12700 9500 6250
Correction coefficients depending on material and temperature (see diagram above).
5.4.3 Auxiliary connections
DANGER
Risk of potentially explosive atmosphere by incompatible fluids mixing in the
auxiliary piping
Risk of burns!
Explosion hazard!
▷ Make sure that the barrier fluid or quench liquid are compatible with the fluid
handled.
WARNING
Failure to use or incorrect use of auxiliary connections (e.g. barrier fluid, flushing
liquid, etc.)
Risk of injury from escaping fluid!
Risk of burns!
Malfunction of the pump!
▷ Refer to the general arrangement drawing, the piping layout and pump
markings (if any) for the quantity, dimensions and locations of auxiliary
connections.
▷ Use the auxiliary connections provided.
