HPK
1121.8/06-EN
Part. No. Comprising Description
102 102 Volute casing
411.01/.02/.03/.04/.10 Joint ring
502.01
20)
Casing wear ring
561.01
20)
Parallel pin
902.01 Stud
903.01/.02/.03/.04 Screw plug
920.01 Hexagon nut
161 161 Casing cover
411.18/.19
21)
Joint ring
463.01 Drip plate
550.01 Disc
902.02 Stud
903.18/.19
21)
Screw plug
920.02 Hexagon nut
183 183 Support foot
901.04
22)
Hexagon head bolt
930.01 Spring washer
210 210 Shaft
920.21 Slotted round nut
931.01 Lock washer
940.01/.02 Key
230 230 Impeller
411.32 Joint ring
320.02 320.02 Angular contact ball bearing
322.01 322.01 Cylindrical roller bearing
330 330 Bearing bracket
360.01/.02 Bearing cover
400.01/.02 Gasket
411.46 Joint ring
421.01/.02 Lip seal
550.23 Support disc
638 Constant level oiler
672 Vent plug
903.46 Screw plug
914.01/.02 Hexagon socket head cap screw
932.01/.02 Circlip
344 344 Bearing bracket lantern
902.04 Stud
901.31 Hexagon head bolt
920.04 Hexagon nut
360 360 Bearing cover
400.01/.02 Gasket
914.01/.02 Hexagon socket head cap screw
400 400 Gasket
20
On HPK-S/SX/SY only
21
Not on HPK-EX/SX
22
On bearing bracket P02as/P04as: socket head cap screw 914.04
