KSB Hya-Solo DSV Series User Manual

5 Description
11 of 44
Hya-Solo DSV
5 Description
5.1 General description
▪ Pressure booster system
5.2 Designation
Example: Hya-Solo DSV / 04 05 / 2 - 4
Table4: Designation key
Code Description
Hya-Solo Pressure booster system with one pump
DSV Model with three-phase motor, speed-controlled, pressure-
dependent starting and flow-dependent stopping
04 Pump size
05 Number of stages per pump
2 - 4 Inlet pressure in bar
5.3 Name plate
Werk-Nr.
51w5102.rN-neireS:noitisoPV 3052/1 B/VSD oloS- ayH
Förderstrom 22,0 m3/h Druckbehälter: Motorleistung P2 1 x 5,50 kW
Anlagensolldruck (p
E
) 5,0 bar Vorpreßdruck 4,5 bar Betriebsspannung / Frequenz Hz
Förderhöhe 49,5 m Inhalt Bruttovolumen 8,0 Liter Steuerspannung / Frequenz Hz
05,21mortsnnenrotoMm2,560=Q ieb ehöhredröF
A
:.rN nalptlahcSrab5,0kcurdroV
Betriebsdruck max. 16,0 bar
! nethcaeb gnutielnasbeirteB emhanbeirtebnI roVynamreG ni edaM ZNI 1448J
9972904032
100
1 2 3
4
5
6
7
8
9
101112
18
17
16
13
14
15
Johann-Klein-Straße 9
Deutschland
67227 Frankenthal
KSB SE & Co. KGaA
Fig.2: Name plate (example) of a Hya-Solo DSV
1 Type series, size 2 Order item number
3 Order number 4 Series code
5 Motor power P2 6 Operating voltage/frequency
7 Control voltage/frequency 8 Nominal motor current
9 Circuit diagram 10 Gross vol. content
11 Pre-charge pressure 12 Accumulator
13 Maximum operating pressure 14 Inlet pressure
15 Head at Q=0 16 Head
17 System setpoint pressure 18 Flow rate
5.4 Design details
Design
The pressure booster system consists of a non-self-priming multistage high-pressure
centrifugal pump with suction and discharge side shut-off valves. The shut-off valves
enable dismantling of the pump or check valve without draining the piping system.
The check valve on the discharge side prevents backflow through the pump when the
pump is not running and reduces the load on the mechanical seal.
An accumulator, a pressure transmitter and a pressure gauge are fitted on the
discharge side of the pressure booster system.
The PumpDrive speed control system is mounted on and ready-wired to the pump
set.
The system comes with separate rubber anti-vibration pads.
