KSB Omega User Manual

Installation
type
Illustration Description
Figure DK Pump on base frame and drive on drive
lantern with support
Vertical installation
Figure DP Pump on base frame, drive on support frame
4.2 Designation
Example: Omega V 150 - 460 A GB P M
Table 7: Designation key
Code Description
Omega Type series
V Design
2)
Horizontal installation
V Vertical installation
150 Nominal discharge nozzle diameter [mm]
460 Nominal impeller diameter [mm]
A Impeller type
GB Material variant
GB Grey cast iron / bronze
GC Grey cast iron / chrome steel
SB Nodular cast iron / bronze
SC Nodular cast iron / chrome steel
DD
35
Duplex stainless steel / duplex stainless steel
P Shaft seal
P Gland packing
G Mechanical seal
M Bearing lubrication
F Grease
M Fluid handled
2)
Blank
4 Description of the Pump (Set)
18 of 94
Omega / Omega V

KSB Omega Specifications

General

Application	Water supply, irrigation
Operating pressure	Up to 16 bar
Speed	2900 rpm, 1450 rpm
Connection Size	DN 32 to DN 400
Housing Material	Cast iron, stainless steel
Impeller Material	Bronze, stainless steel, cast iron
Seal Type	Mechanical seal
Operating Temperature	-10°C to +120°C
