3 Transport/Temporary Storage/Disposal
3.1 Checking the condition upon delivery
1. On transfer of goods, check each packaging unit for damage.
2. In the event of in-transit damage, assess the exact damage, document it and
notify KSB or the supplying dealer (as applicable) and the insurer about the
damage in writing immediately.
3.2 Transport
DANGER
Lifting lugs of pump/motor/base frame overloaded
Danger to life from falling parts!
▷ Never transport the pump set components (pump/motor/base frame) in any way
other than as described in the Transport section.
▷ Refer to the weights of the individual components stated in the manufacturer's
product literature.
DANGER
The pump (set) could slip out of the suspension arrangement
Danger to life from falling parts!
▷ Always transport the pump (set) in the specified position.
▷ Never attach the suspension arrangement to the free shaft end or the motor
eyebolt.
▷ Give due attention to the weight data and the centre of gravity.
▷ Observe the applicable local health and safety regulations.
▷ Use suitable, permitted lifting accessories, e.g. self-tightening lifting tongs.
For transporting the motor, observe the motor supplier's product literature!
To transport the pump/pump set suspend it from the lifting tackle as shown.
Fig. 1: The angle of pull must not be greater than 90°!
3 Transport/Temporary Storage/Disposal
12 of 94
Omega / Omega V
