9 Related Documents
9.1 Weights of individual components
DANGER
Improper transport
Risk of injury from lifting heavy components!
▷ Select lifting accessories which are suitable for the component weight.
▷ Always use the attachment points provided for the lifting accessories.
▷ Comply with the applicable health and safety regulations.
Table 21: Weights of individual components [kg]
Size Volute casing Impeller Shaft Bearing housing Shaft seal
housing
Casing
wear ring
Lower
section
Upper
section
80 - 210 132 48 < 25 < 25 < 25 < 25 < 25
80 - 270 134 48 < 25 < 25 < 25 < 25 < 25
80 - 370 140 54 < 25 < 25 < 25 < 25 < 25
100 - 250 152 52 30 < 25 < 25 < 25 < 25
100 - 310 150 54 30 < 25 < 25 < 25 < 25
100 - 375 170 61 35 < 25 < 25 < 25 < 25
125 - 230 226 66 30 < 25 < 25 < 25 < 25
125 - 290 231 70 30 < 25 < 25 < 25 < 25
125 - 365 234 79 55 < 25 < 25 < 25 < 25
125 - 500 285 110 55 < 25 < 25 < 25 < 25
150 - 290 253 88 53 < 25 < 25 < 25 < 25
150 - 360 255 92 53 < 25 < 25 < 25 < 25
150 - 460 307 109 95 < 25 < 25 < 25 < 25
150 - 605 458 168 98 < 25 < 25 < 25 < 25
200 - 320 365 128 67 < 25 < 25 < 25 < 25
200 - 420 389 122 67 < 25 < 25 < 25 < 25
200 - 520 580 200 109 30 27 31 < 25
200 - 670 667 276 109 30 27 31 < 25
250 - 370 540 160 129 30 27 31 < 25
250 - 480 610 202 120 44 32 34 < 25
250 - 600 777 278 119 44 32 34 < 25
250 - 800 1097 509 239 63 35 43 < 25
300 - 300 558 189 87 30 27 31 < 25
300 - 435 725 250 126 44 32 34 < 25
300 - 560 1065 360 194 63 35 43 < 25
300 - 700 1295 444 194 63 35 43 < 25
300 - 860 2064 945 220 108 55 32 < 25
350 - 360 774 252 131 44 32 34 < 25
350 - 430 1050 344 136 63 35 43 < 25
350 - 510 889 378 172 63 35 43 < 25
9 Related Documents
74 of 94
