Rated
power
P
N
[kW]
Surface sound pressure level L
pA
4)
Pump set
3500 rpm 2900 rpm 1750 rpm 1450 rpm 1160 / 870
rpm
960 / 750
rpm
[dB (A)] [dB (A)] [dB (A)] [dB (A)] [dB (A)] [dB (A)]
900 88,2 87,7 85,7 85,1 83,6 82,6
1000 88,5 88,0 86,0 85,5 84,0 83,0
4.7 Scope of supply
Depending on the model, the following items are included in the scope of supply:
▪ Pump
▪ Drive
▪ Baseplate
▪ Coupling, coupling guard
▪ Universal-joint shaft
▪ Fasteners for pump and base frame
Optional accessories:
▪ Vibration monitoring
▪ Pt100 temperature sensor
▪ Pressure gauge
▪ Measuring nipple for shock pulse measurement
▪ Cyclone
4.8 Dimensions and weights
For dimensions and weights please refer to the data sheet of the pump (set).
▪ Pump weight: See name plate of the pump.
▪ Motor weight: See motor product literature.
▪ Weight of the shipping unit base frame with pump: See weight indicated on the
base frame.
▪ Weight of the shipping unit base frame with pump and motor: See weight
indicated on the base frame.
NOTE
Some individual components weigh more than 25 kg. Observe the weights
indicated.( (⇨ Section 9.1 Page 74) or other applicable documents)
4 Description of the Pump (Set)
22 of 94
Omega / Omega V
