WARNING
Hot surface
Risk of injury!
▷ Allow the pump set to cool down to ambient temperature.
WARNING
Components with sharp edges
Risk of cutting or shearing injuries!
▷ Always use appropriate caution for installation and dismantling work.
▷ Wear work gloves.
Observe the general safety instructions and information. (⇨ Section 2.8 Page 10)
For any work on the motor, observe the instructions of the relevant motor
manufacturer.
For dismantling and reassembly refer to the general assembly drawing.
In the event of damage you can always contact our service staff.
7.4.2 Preparing the pump set
DANGER
The pump (set) could slip out of the suspension arrangement
Danger to life from falling parts!
▷ Always transport the pump (set) in the specified position.
▷ Never attach the suspension arrangement to the free shaft end or the motor
eyebolt.
▷ Give due attention to the weight data and the centre of gravity.
▷ Observe the applicable local health and safety regulations.
▷ Use suitable, permitted lifting accessories, e.g. self-tightening lifting tongs.
NOTE
Horizontal installation
The pumps have been designed in such a way that the complete rotor can be
removed and dismantled without the need to remove the suction and discharge
line and without disturbing the alignment of the pump set.
NOTE
Vertical installation
For dismantling a vertically installed pump, the complete pump has to be removed
and placed in a horizontal position. Then, the complete rotor can be removed and
dismantled.
Preparing for dismantling
✓ The gate valves in the suction and discharge lines have been closed.
✓ The motor has been disconnected from the power supply and secured against
unintentional start-up.
✓ The pump has been drained.
1. Remove the flushing line and any auxiliary feed lines connected to the pump.
2. Remove the coupling guard and any other guards.
3. Separate the pump from the motor.
7 Servicing/Maintenance
54 of 94
Omega / Omega V
