KTM 125 Repair Manual

Repair manual 125 / 200
Art No 3.206.005-E
TECHNICAL SPECIFICATIONS
MODEL 1999
TECHNICAL SPECIFICATIONS – ENGINE 125/200 . . . . . . . . . . . . . . . . . . . .9-2
TECHNICAL SPECIFICATIONS – CHASSIS 125/200 . . . . . . . . . . . . . . . . . . .9-4
TECHNICAL SPECIFICATIONS – ENGINE 200 ONLY SINGAPORE . . . . . . . . .9-5
BASIC CARBURETOR SETTING – 200 ONLY SINGAPORE . . . . . . . . . . . . . .9-5
MODEL 2000
TECHNICAL SPECIFICATIONS – ENGINE 125 EXE, SUPERMOTO . . . . . . . . .9-6
TECHNICAL SPECIFICATIONS – CHASSIS 125 EXE, SUPERMOTO . . . . . . . .9-7
TECHNICAL SPECIFICATIONS – ENGINE 125/200 SX, MXC, EXC . . . . . . . .9-8
TECHNICAL SPECIFICATIONS – CHASSIS 125/200 SX, MXC, EXC . . . . . . .9-10
MODEL 2001
TECHNICAL SPECIFICATIONS – ENGINE 125 EXE, SUPERMOTO . . . . . . . . .9-6
TECHNICAL SPECIFICATIONS – CHASSIS 125 EXE, SUPERMOTO . . . . . . . .9-7
TECHNICAL SPECIFICATIONS – ENGINE 125/200 . . . . . . . . . . . . . . . . . . .9-11
TECHNICAL SPECIFICATIONS – CHASSIS 125/200 . . . . . . . . . . . . . . . . . .9-13
MODEL 2002
TECHNICAL SPECIFICATIONS – ENGINE 125/200 . . . . . . . . . . . . . . . . . . .9-14
TECHNICAL SPECIFICATIONS – CHASSIS 125/200 . . . . . . . . . . . . . . . . . .9-16
MODEL 2003
TECHNICAL SPECIFICATIONS – ENGINE 125/200 . . . . . . . . . . . . . . . . . . .9-17
TECHNICAL SPECIFICATIONS – CHASSIS 125/200 . . . . . . . . . . . . . . . . . .9-19
CARBURATOR SPECIFICATION
MODEL 1999 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-21
MODEL 2000 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-24
MODEL 2001 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-27
MODEL 2002 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-30
MODEL 2003 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-33
INDEX
9-1C
9

KTM 125 Specifications

General

Bore x Stroke	54 mm x 54.5 mm
Starter	Kickstarter
Transmission	6-speed
Engine Type	Single-cylinder, 2-stroke
Displacement	124.8 cm³
Cooling System	Liquid cooled
Fuel System	Carburetor
Lubrication	Premix (oil-fuel mixture)
