Page #178 background image
23 TECHNICAL DATA 176
Front 320 mm (12.6 in)
Rear 240 mm (9.45 in)
Brake discs - wear limit
Front 4.5 mm (0.177 in)
Rear 4.5 mm (0.177 in)
Tire air pressure, solo/with passenger/full payload
Front: with cold tires 2.5 bar (36 psi)
Rear: with cold tires 2.9 bar (42 psi)
Secondary drive ratio 17:38
Chain 5/8 x 5/16” (525) Xring
Steering head angle 65.1°
Wheelbase 1,482 mm (58.35 in)
Seat height unloaded 835 mm (32.87 in)
Ground clearance unloaded 141 mm (5.55 in)
Weight without fuel approx. 189 kg (417 lb.)
Maximum permissible front axle load 160 kg (353 lb.)
Maximum permissible rear axle load 260 kg (573 lb.)
Maximum permissible overall weight 406 kg (895 lb.)
23.5 Electrical system
Battery YTX14-BS Battery voltage: 12 V
Nominal capacity: 12 Ah
Maintenance-free
Fuse 58011109110 10 A
Fuse 58011109115 15 A
