13 SERVICE WORK ON THE CHASSIS 92
13.6 Mounting the passenger seat
401922-10
–
Attach the recesses of the passenger seat in the guides
and lower at the front while
pushing it back.
–
Position locking pin
in the lock housing and push down the passenger seat at the
front.
The locking pin engages with an audible click.
– Check that the passenger seat is correctly mounted.
13.7 Removing the front rider's seat
Preparatory work
– Remove the passenger seat. ( p. 91)
B02310-10
Main work
– Raise the rear of the front rider's seat.
– Detach the front of the front rider's seat and remove it.
