6 CONTROLS 27
6.4.4 Menu switch
L01406-12
The menu switch is fitted in the middle of the left combination switch.
The menu buttons are used to control the matrix display on the combination instrument.
Button
is the UP button.
Button
is the DOWN button.
Button
is the SET button.
Button
is the BACK button.
6.4.5 Turn signal switch
L01406-13
The turn signal switch
is fitted on the combination switch on the left.
Possible states
Turn signal off – Press the turn signal switch.
Turn signal, left, on – Turn signal switch pressed to the left. The turn signal
switch returns automatically to the central position after use.
Turn signal, right, on – Turn signal switch pressed to the right. The turn
signal switch returns automatically to the central position after use.
To switch off the turn signal, press the turn signal switch towards the switch case.
