23 TECHNICAL DATA 180

23.9 Chassis tightening torques

Remaining screws, chassis EJOT PT

K50x12 1 Nm (0.7 lbf ft) –

Remaining screws, chassis EJOT PT

K50x14 1 Nm (0.7 lbf ft) –

Remaining screws, chassis EJOT PT

K50x16 2 Nm (1.5 lbf ft) –

Remaining screws, chassis EJOT PT

K50x18 2 Nm (1.5 lbf ft) –

Screw, fuel tank cover, quick connect

nipple

EJOT PT

K60 2 Nm (1.5 lbf ft) –

Screw, tail light EJOT PT

K50x14 2.5 Nm (1.84 lbf ft) –

Screw, combination switch, left M4 2.5 Nm (1.84 lbf ft) –

Screw, side stand switch M4 2 Nm (1.5 lbf ft) –

Remaining nuts, chassis M5 5 Nm (3.7 lbf ft) –

Remaining screws, chassis M5 5 Nm (3.7 lbf ft) –

Screw, cable channel M5 5 Nm (3.7 lbf ft) –

Screw, chain sliding guard M5 5 Nm (3.7 lbf ft) –

Screw, combination switch, right M5 3.5 Nm (2.58 lbf ft) –

Screw, cover part M5x12 3.5 Nm (2.58 lbf ft) –

Screw, filler cap M5 3 Nm (2.2 lbf ft) –

Screw, fuel level indicator M5 3 Nm (2.2 lbf ft) –

Screw, shock absorber adjusting ring M5 5 Nm (3.7 lbf ft) –

Ground fitting on frame M6 10 Nm (7.4 lbf ft) –

Nut, ABS unit attachment M6 5 Nm (3.7 lbf ft) –

Nut, cable on starter motor M6 4 Nm (3 lbf ft) –

Remaining nuts, chassis M6 10 Nm (7.4 lbf ft) –

Remaining screws, chassis M6 10 Nm (7.4 lbf ft) –
