23 TECHNICAL DATA 181
Screw, ball joint of push rod on foot
brake cylinder
M6 5 Nm (3.7 lbf ft) Loctite
®
243™
Screw, battery terminal M6 4.5 Nm (3.32 lbf ft) –
Screw, clutch assembly M6 5 Nm (3.7 lbf ft) Loctite
®
243™
Screw, connecting piece, rear brake line M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, cooler retaining bracket M6 7 Nm (5.2 lbf ft) –
Screw, exhaust clamp on main silencer M6 8 Nm (5.9 lbf ft) –
Screw, exhaust clamp on manifold M6 8 Nm (5.9 lbf ft) –
Screw, foot brake cylinder M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, fuel pump M6 6 Nm (4.4 lbf ft) –
Screw, headlight mask, rear wall M6 5 Nm (3.7 lbf ft) –
Screw, license plate holder on lower rear
panel
M6 12 Nm (8.9 lbf ft) –
Screw, radiator hose clamp M6 3 Nm (2.2 lbf ft) –
Screw, sensor box M6 6 Nm (4.4 lbf ft) Loctite
®
243™
Screw, shift lever stub M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, shift rod M6 5 Nm (3.7 lbf ft) Loctite
®
243™
Screw, shift shaft deflector on shift
shaft
M6 18 Nm (13.3 lbf ft) Loctite
®
243™
Screw, side stand stub M6 6 Nm (4.4 lbf ft) Loctite
®
243™
Screw, steering damper, holder, on
frame
M6 8 Nm (5.9 lbf ft) Loctite
®
243™
Screw, step plate for foot brake lever M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, wheel speed sensor, front M6 4 Nm (3 lbf ft) –
Screw, wheel speed sensor, rear M6 4 Nm (3 lbf ft) –
