23 TECHNICAL DATA 182

Nut, manifold on cylinder head M8 Tightening sequence:

Tighten the nuts evenly. Do

not warp the metal plate.

25 Nm (18.4 lbf ft)

–

Nut, rear sprocket M8 36 Nm (26.6 lbf ft) –

Nut, shift rod M8 12 Nm (8.9 lbf ft) –

Nut, shift rod M8LH 12 Nm (8.9 lbf ft) –

Nut, valve, angled M8 4 Nm (3 lbf ft) –

Remaining nuts, chassis M8 25 Nm (18.4 lbf ft) –

Remaining screws, chassis M8 25 Nm (18.4 lbf ft) –

Screw, axle clamp M8 15 Nm (11.1 lbf ft) –

Screw, bottom triple clamp M8 12 Nm (8.9 lbf ft) –

Screw, foot brake lever M8 20 Nm (14.8 lbf ft) Loctite

243™

Screw, front brake disc M8 30 Nm (22.1 lbf ft) Loctite

2701™

Screw, front rider footrest bracket M8 25 Nm (18.4 lbf ft) Loctite

243™

Screw, handlebar clamp M8 20 Nm (14.8 lbf ft) –

Screw, ignition lock (tamper-proof

screw)

M8 25 Nm (18.4 lbf ft) –

Screw, rear brake caliper M8 25 Nm (18.4 lbf ft) Loctite

2701™

Screw, rear brake disc M8 30 Nm (22.1 lbf ft) Loctite

243™

Screw, shift lever on footrest bracket M8 20 Nm (14.8 lbf ft) Loctite

243™

Screw, shift shaft deflector on frame M8 10 Nm (7.4 lbf ft) Loctite

243™

Screw, side stand bracket M8 25 Nm (18.4 lbf ft) Loctite

243™

Screw, side stand spring M8 15 Nm (11.1 lbf ft) Loctite

2701™

Screw, steering damper on holder M8 8 Nm (5.9 lbf ft) Loctite

243™
