23 TECHNICAL DATA 183

Screw, steering damper on triple clamp M8 8 Nm (5.9 lbf ft) Loctite

243™

Screw, top triple clamp M8 15 Nm (11.1 lbf ft) –

Remaining nuts, chassis M10 45 Nm (33.2 lbf ft) –

Remaining screws, chassis M10 45 Nm (33.2 lbf ft) –

Screw, engine bearer M10 45 Nm (33.2 lbf ft) Loctite

243™

Screw, front brake caliper M10 45 Nm (33.2 lbf ft) Loctite

243™

Screw, instrument support M10 40 Nm (29.5 lbf ft) Loctite

243™

Screw, side stand M10 35 Nm (25.8 lbf ft) Loctite

243™

Screw, side stand bracket M10 45 Nm (33.2 lbf ft) Loctite

243™

Screw, side stand retaining plate M10 45 Nm (33.2 lbf ft) Loctite

243™

Banjo bolt, brake line M10x1 25 Nm (18.4 lbf ft) –

Banjo bolt, brake line, connecting piece,

rear

M10x1 15 Nm (11.1 lbf ft) –

Nut, rear hub shock absorber carrier M10x1.25 45 Nm (33.2 lbf ft) Loctite

243™

Lambda sensor M12x1.25 25 Nm (18.4 lbf ft) –

Screw, bottom shock absorber M14x1.5 80 Nm (59 lbf ft) Thread greased

Screw, top shock absorber M14x1.5 80 Nm (59 lbf ft) Thread greased

Screw, eccentric M16 70 Nm (51.6 lbf ft) –

Nut, swingarm pivot M19x1.5 130 Nm (95.9 lbf ft) Thread greased

Nut, seat lock M22x1.5 6 Nm (4.4 lbf ft) –

Screw, steering head, top M22x1.5 50 Nm (36.9 lbf ft) –

Bolt, front axle M25x1.5 45 Nm (33.2 lbf ft) Thread greased
