22 TECHNICAL DATA
136
Screw, crankshaft speed sensor M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, exhaust control bearing
support
M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, exhaust control cap M5 5 Nm (3.7 lbf ft)
Screw, exhaust control cover M5 4 Nm (3 lbf ft)
Screw, locking lever M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, retaining bracket of exhaust
control
M5 6 Nm (4.4 lbf ft)
Loctite
®
2701™
Bleeder screw, cylinder head M6 10 Nm (7.4 lbf ft)
Cap nut, water pump impeller M6 5 Nm (3.7 lbf ft)
Loctite
®
243™
Nut, adjusting screw, power valve M6 8 Nm (5.9 lbf ft)
Screw, alternator cover M6 8 Nm (5.9 lbf ft)
Screw, clutch slave cylinder M6 10 Nm (7.4 lbf ft)
Screw, control flap, exhaust con-
trol
M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, engine case M6 10 Nm (7.4 lbf ft)
Screw, exhaust control thrust bear-
ing
M6 8 Nm (5.9 lbf ft)
Loctite
®
243™
Screw, exhaust flange M6 8 Nm (5.9 lbf ft)
Screw, gear oil level monitoring M6 8 Nm (5.9 lbf ft)
Screw, intake flange/reed valve
housing
M6 6 Nm (4.4 lbf ft)
Screw, intermediate clutch cover M6 10 Nm (7.4 lbf ft)
Screw, kick starter intermediate
gear steel pin
M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, outer clutch cover M6 8 Nm (5.9 lbf ft)
Screw, shift drum locating M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, shift lever M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, starter motor M6 10 Nm (7.4 lbf ft)
Screw, starter motor bearing bush M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, starter motor protection cap M6 8 Nm (5.9 lbf ft)
Screw, stator M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, water pump cover M6 10 Nm (7.4 lbf ft)
Vacuum connection, housing
breather
M6 2 Nm (1.5 lbf ft)
Loctite
®
243™
Screw, balancer shaft M8 30 Nm (22.1 lbf ft)
Loctite
®
243™
Screw, cylinder head M8 27 Nm (19.9 lbf ft)
Nut, cylinder base M10 35 Nm (25.8 lbf ft)
Screw, drive chain engine sprocket M10 60 Nm (44.3 lbf ft)
Loctite
®
2701™
