6 CONTROLS 13
6.9 Shift lever
601938-10
Shift lever 1 is mounted on the left side of the engine.
601939-10
The gear positions can be seen in the photograph.
The neutral or idle position N is between the first and second gears.
6.10 Kickstarter
601941-10
The kickstarter 1 is fitted on the right of the engine.
The kickstarter can be swiveled.
Info
Before riding, swing the kickstarter inwards towards the engine.
6.11 Foot brake lever
601940-10
Foot brake lever 1 is located in front of the right footrest.
The foot brake lever is used to activate the rear brake.
6.12 Plug-in stand
602658-10
The fixture for the plug-in stand 1 is located on the frame on the left side of the vehi-
cle.
The plug-in stand is used to park the motorcycle.
Info
Remove the plug-in stand before riding.
