KTM 65 SX - Installing the Start Number Plate; Dismounting the Front Fender; Installing the Front Fender

11 SERVICE WORK ON THE CHASSIS 34
11.15 Installing the start number plate
602673-10
– Position the start number plate with the drill holes onto the holding lugs 1 of the
fender.
602672-11
– Mount and tighten screw 2.
Guideline
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
– Position the brake line. Put the clamp on, mount and tighten screw 3.
11.16 Dismounting the front fender
602674-10
– Remove screws 1. Remove the front fender.
11.17 Installing the front fender
602675-10
– Position the fender with holding lugs 1 into the drill holes on the start number
plate.
602674-11
– Position the front fender. Mount and tighten screws 2.
Guideline
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
