11 SERVICE WORK ON THE CHASSIS 39
602686-10
Main work
– Remove screw 1.
602687-10
– Remove screws 2.
601955-11
– Pull off fuel hose 3.
Info
Remaining fuel may run out of the fuel hose.
– Pull both spoilers off of the side of the radiator bracket and lift off the fuel tank.
11.29 Installing the fuel tank x
Danger
Fire hazard Fuel is highly flammable.
– Never refuel the vehicle near open flames or burning cigarettes, and always switch off the engine first. Be careful that no
fuel is spilt, especially on hot vehicle components. Clean up spilt fuel immediately.
– The fuel in the fuel tank expands when warm and may emerge if overfilled. Follow the instructions on refueling.
Warning
Danger of poisoning Fuel is poisonous and a health hazard.
– Fuel must not come into contact with the skin, eyes, or clothing. Do not breathe in the fuel vapors. If contact occurs with
the eyes, rinse with water immediately and contact a physician. Immediately clean contaminated areas on the skin with
soap and water. If fuel is swallowed, contact a physician immediately. Change clothing that is contaminated with fuel.
Store fuel properly in a suitable canister and keep away from children.
601955-10
Main work
– Position the fuel tank and attach both spoilers onto the sides of the radiator
bracket.
– Ensure that cables are not pinched or damaged.
– Connect fuel hose 1.
