TECHNICAL DATA - ENGINE TIGHTENING TORQUES 78
Screw, cylinder head M10 Tightening sequence:
Tighten diagonally, begin-
ning with the rear screw on
the chain shaft.
Step 1
15 Nm (11.06 lbf ft)
Step 2
30 Nm (22.13 lbf ft)
Step 3
45 Nm (33.19 lbf ft)
Step 4
60 Nm (44.26 lbf ft)
Engine oil (any)
Temperature switch VDO M10x1 4 Nm (2.95 lbf ft)
Loctite
®
243™
Adapter for coolant sensor on cylinder
head
M12x1.5 12 Nm (8.85 lbf ft) –
Coolant temperature sensor on cylinder
head
M12x1.5 12 Nm (8.85 lbf ft) –
Oil drain plug with magnet M12x1.5 20 Nm (14.75 lbf ft) –
Plug, excess pressure valve M12x1.5 20 Nm (14.75 lbf ft) –
Spark plug M12x1.25 17 Nm (12.54 lbf ft) –
Plug, oil bore M14x1.5 15 Nm (11.06 lbf ft)
Loctite
®
243™
Ignition rotor nut M18x1.5 100 Nm (73.76 lbf ft) –
Nut, engine sprocket M20x1.5 60 Nm (44.26 lbf ft)
Loctite
®
243™
Nut, inner clutch hub M20x1.5 100 Nm (73.76 lbf ft)
Loctite
®
243™
Nut, primary gear M20LHx1.5 100 Nm (73.76 lbf ft)
Loctite
®
243™
Plug, oil screen M20x1.5 15 Nm (11.06 lbf ft) –
Plug, timing chain tensioner M20x1.5 25 Nm (18.44 lbf ft) –
Screw in ignition cover M24x1.5 8 Nm (5.9 lbf ft) –
Plug, oil thermostat M24x1.5 15 Nm (11.06 lbf ft) –
