KTM 690 - Page 89

WIRING DIAGRAM 87
Components:
G1 Battery
G2 Generator
K1 Starter relay with fuse
K3 High beam relay
K4 Low beam relay
M1 Starter motor
M2 Radiator fan
N1 Voltage regulator/rectifier
S2 Gear sensor switch
S4 Temperature switch for radiator fan
S5 Ignition lock
S6 Electric starter button
Cable colors:
1 green
2 green
3 green
4 green
5 green
6 green
7 yellow-red
8 green
9 yellow-red
10 yellow-red
11 yellow-red
12 yellow-red
13 yellow-red
14 yellow-red
15 orange
16 black-orange
17 white-black
18 yellow-blue
19 yellow
20 black-red
21 gray
22 yellow
23 yellow
24 green-red
25 white-yellow
26 blue
27 brown
28 green-orange
29 orange
30 brown
31 blue-orange
32 brown
33 brown
41 brown
42 white-red
43 brown
44 brown
47 white-green
