KTM 890 ADVENTURE R 2023 User Manual

WHEELS, TIRES 15
121
15.2 Installing the front wheel
Warning
Danger of accidents Oil or grease on the brake discs reduces the braking effect.
– Always keep the brake discs free of oil and grease.
– Clean the brake discs with brake cleaner when necessary.
F01964-11
– Check the wheel bearing for damage and wear.
» If the wheel bearing is damaged or worn:
– Change front wheel bearing.
–
Clean and grease shaft seal rings
1
and contact surfaces
A
of the spacers.
Long-life grease ( p. 172)
R06222-10
–
Insert narrow spacer
2
on the right in the direction of travel.
–
Insert wide spacer
3
on the left in the direction of travel.
Info
Arrow
B
indicates the direction of travel of the front
wheel.
The wheel speed sensor wheel is on the left viewed in
the direction of travel.
F02069-10
–
Clean screw
4
and the wheel spindle.
– Grease wheel spindle lightly.
Long-life grease ( p. 172)
– Jack up the front wheel into the fork, position it, and insert the
wheel spindle.
–
Mount and tighten screw
4
.
Guideline
Screw, front
wheel spindle
M25x1.5 45 Nm (33.2 lbf ft)
Thread greased

KTM 890 ADVENTURE R 2023 Specifications

General

Engine Type	2-cylinder, 4-stroke, parallel twin
Displacement	889 cc
Transmission	6-speed
Front Suspension	WP XPLOR-USD, Ø 48 mm
Bore x Stroke	90.7 mm x 68.8 mm
Compression Ratio	13.5:1
Fuel System	Electronic Fuel Injection
Final Drive	Chain
Front Tire	90/90-21
Rear Tire	150/70-18
Cooling	Liquid cooled
Lubrication	Forced oil lubrication with 2 oil pumps
Frame	Chromium-Molybdenum-Steel frame using the engine as stressed element, powder coated
Power	105 hp (77 kW) @ 8, 000 rpm
Torque	100 Nm
Fuel Tank Capacity	20 liters
Seat Height	880 mm (34.6 in)
Dry Weight	196 kg (432 lb)
Rear Suspension	WP XPLOR PDS shock absorber
Front Brake	2x radially mounted 4-piston calipers
Rear Brake	2-piston floating caliper
ABS	Bosch 9.1 MP (incl. Cornering-ABS and offroad mode)
Wheels Front	21"
Wheels Rear	18"
Chain	520
Steering Head Angle	63.5°
Ground Clearance	263 mm
