7 COMBINATION INSTRUMENT
32
7.1 Combination instrument
I00194-10
The combination instrument is attached in front of the handlebar.
The combination instrument is divided into two function areas.
1
indicator lamps ( p. 35)
Display
2
Caution
Danger of burnsParts of the combination instrument become very hot in certain situations.
In particular, the display gets hot in ambient temperatures above 55 °C (131 °F), during extended sta-
tionary periods, for example, at a traffic light, or in direct sunlight.
Do not touch the combination instrument with bare hands in the situations referred to.
Where appropriate protective clothing.
If you have been burned, hold the area affected under lukewarm water immediately.
7.2 Activation and test
I00195-01
Activation
The combination instrument is activated when the ignition is
switched on.
Info
The brightness of the displays is controlled by an ambient
light sensor in the combination instrument.
Test
The welcome text appears on the display and all indicator lamps
are briefly activated for a function check.
