KTM 890 ADVENTURE R 2023 User Manual

CONTROLS 6
21
6.4.2 Light switch
I00282-10
The light switch
1
is fitted on the combination switch on the
left.
Possible states
Low beam on – Light switch in position
A
. In this
position, the low beam and the tail light are switched
on.
High beam on – Push the light switch to position
B
.
In this position, the high beam and the tail light are
switched on.
Headlight flasher – Push the light switch into posi-
tion
C
.
6.4.3 Cruise control system tip switch
V01193-10
The cruise control system tip switch
1
is fitted on the left side of
the combination switch.
Info
The cruise control system function (optional) must be acti-
vated to be able to use the cruise control system tip switch.
Possible states
• Cruise control system tip switch in the basic position.
• Cruise control system tip switch pressed to the left. – In
this position, the cruise control system function is switched
on and off. The operating mode is displayed in the combina-
tion instrument.
• Briefly press cruise control system tip switch at the top.
– The last saved speed is reached and maintained. Every sub-
sequent brief pressing increases the target speed by 1 km/h
or 1 mph.
• Press and hold cruise control system tip switch at the top.
– The target speed increases in increments of 5 km/h or
5 mph.
• Briefly press cruise control system tip switch at the bottom.
– The cruise control function is activated and the current
speed is maintained. Every subsequent brief press reduces
the target speed by 1 km/h or 1 mph.
• Press and hold cruise control system tip switch at the bot-
tom. – The target speed decreases in increments of 5 km/h or
5 mph.
Info
After activating the cruise control function, the throttle
grip can be turned back to the basic position. The selected
speed will be maintained.
If the cruise speed is exceeded for less than 30 seconds
by turning the throttle grip, the cruise control remains acti-
vated.
To switch off the cruise control system function, press the
cruise control system tip switch to the left.
In addition, the cruise control system function is deactivated when
one of the following events occurs:

KTM 890 ADVENTURE R 2023 Specifications

General

Engine Type	2-cylinder, 4-stroke, parallel twin
Displacement	889 cc
Transmission	6-speed
Front Suspension	WP XPLOR-USD, Ø 48 mm
Bore x Stroke	90.7 mm x 68.8 mm
Compression Ratio	13.5:1
Fuel System	Electronic Fuel Injection
Final Drive	Chain
Front Tire	90/90-21
Rear Tire	150/70-18
Cooling	Liquid cooled
Lubrication	Forced oil lubrication with 2 oil pumps
Frame	Chromium-Molybdenum-Steel frame using the engine as stressed element, powder coated
Power	105 hp (77 kW) @ 8, 000 rpm
Torque	100 Nm
Fuel Tank Capacity	20 liters
Seat Height	880 mm (34.6 in)
Dry Weight	196 kg (432 lb)
Rear Suspension	WP XPLOR PDS shock absorber
Front Brake	2x radially mounted 4-piston calipers
Rear Brake	2-piston floating caliper
ABS	Bosch 9.1 MP (incl. Cornering-ABS and offroad mode)
Wheels Front	21"
Wheels Rear	18"
Chain	520
Steering Head Angle	63.5°
Ground Clearance	263 mm
