TECHNICAL SPECIFICATIONS 23
163
Comfort 4 turns
Standard 4 turns
Sport 4 turns
Full payload 10 turns
Fitted length 380 mm (14.96 in)
Spring length 201.3 mm (7.925 in)
Spring rate
Weight of rider: 75 … 85 kg (165 … 187 lb.) 95 N/mm (542 lb/in)
Gas pressure 16 bar (232 psi)
Damper oil Shock absorber fluid (SAE 2.5)
(50180751S1) ( p. 171)
23.9 Chassis tightening torques
Brake fluid reservoir cover, front - 2 Nm (1.5 lbf ft)
Brake fluid reservoir cover, rear - 1.5 Nm (1.11 lbf ft)
Compensating tank cover - 1.1 Nm (0.81 lbf ft)
Nut, valve ISO 10V2 12 Nm (8.9 lbf ft)
Loctite
®
2701™
Remaining screws, chassis EJOTPT
®
K45x12 1 Nm (0.7 lbf ft)
Remaining screws, chassis EJOTPT
®
K50x12 1 Nm (0.7 lbf ft)
Remaining screws, chassis EJOTPT
®
K50x14 1 Nm (0.7 lbf ft)
Remaining screws, chassis EJOTPT
®
K50x16 2 Nm (1.5 lbf ft)
Remaining screws, chassis EJOTPT
®
K50x18 2 Nm (1.5 lbf ft)
Screw, inside cover on radiator EJOT PT
®
K50x18 4.5 Nm (3.32 lbf ft)
Screw, tail light EJOT DELTA PT
®
45x12‑Z 1.5 Nm (1.11 lbf ft)
Socket for electrical accessories - 4 Nm (3 lbf ft)
Throttle valve body hose clamp - 2.8 Nm (2.07 lbf ft)
Remaining nuts, chassis M4 3 Nm (2.2 lbf ft)
Remaining screws, chassis M4 3 Nm (2.2 lbf ft)
Screw, fixed grip, left M4 3 Nm (2.2 lbf ft)
Remaining nuts, chassis M5 5 Nm (3.7 lbf ft)
Remaining screws, chassis M5 5 Nm (3.7 lbf ft)
Screw for throttle grip M5 3.5 Nm (2.58 lbf ft)
Screw, air filter box M5 3 Nm (2.2 lbf ft)
Screw, brake fluid reservoir for rear
brake
M5 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, brake line holder on link
fork
M5 1 Nm (0.7 lbf ft)
Screw, combination instrument M5 1 Nm (0.7 lbf ft)
Screw, combination switch, left M5 2 Nm (1.5 lbf ft)
Screw, combination switch, right M5 5 Nm (3.7 lbf ft)
Screw, engine sprocket cover M5 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, foot brake lever stub M5 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, fork protector M5x12 5 Nm (3.7 lbf ft)
