22 TECHNICAL DATA
130
Screw, shift lever M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, starter motor M6 10 Nm (7.4 lbf ft)
Screw, timing chain guide rail M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, timing chain securing guide M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, valve cover M6 8 Nm (5.9 lbf ft)
Screw, water pump cover M6 10 Nm (7.4 lbf ft)
Stud, cylinder head M6 10 Nm (7.4 lbf ft)
Screw, camshaft bearing bridge M7x1 14 Nm (10.3 lbf ft)
Lubricated with engine oil
Screw plug, crankshaft location M8 10 Nm (7.4 lbf ft)
Screw, timing chain tensioning rail M8 15 Nm (11.1 lbf ft)
Loctite
®
243™
Screw, engine sprocket M10 60 Nm (44.3 lbf ft)
Loctite
®
2701™
Plug, oil channel M10x1 15 Nm (11.1 lbf ft)
Loctite
®
243™
Screw plug, cam lever axis M10x1 10 Nm (7.4 lbf ft)
Screw, rotor M10x1 70 Nm (51.6 lbf ft)
Collar and thread oiled / cone
degreased
Screw, unlocking of timing chain
tensioner
M10x1 8 Nm (5.9 lbf ft)
Spark plug M10x1 10 … 12 Nm (7.4 … 8.9 lbf ft)
Engine coolant temperature sensor M10x1.25 12 Nm (8.9 lbf ft)
Nut, cylinder head M10x1.25 Tightening sequence:
Tighten diagonally.
1st tightening stage
10 Nm (7.4 lbf ft)
2nd tightening stage
30 Nm (22.1 lbf ft)
3rd tightening stage
50 Nm (36.9 lbf ft)
Thread, oiled with engine oil/cone
greased
Stud, cylinder head M10x1.25 20 Nm (14.8 lbf ft)
Loctite
®
243™
Oil drain plug with magnet M12x1.5 20 Nm (14.8 lbf ft)
Plug, oil pressure regulator valve M12x1.5 20 Nm (14.8 lbf ft)
Oil drain plug M14x1.5 15 Nm (11.1 lbf ft)
Nut, inner clutch hub M18x1.5 100 Nm (73.8 lbf ft)
Loctite
®
243™
Nut, primary gear M18LHx1.5 100 Nm (73.8 lbf ft)
Loctite
®
243™
Screw plug, oil screen M20x1.5 15 Nm (11.1 lbf ft)
Plug, timing chain tensioner M24x1.5 40 Nm (29.5 lbf ft)
Screw, alternator cover M24x1.5 18 Nm (13.3 lbf ft)
