KTM F8101S5 User Manual

11 SERVICE WORK ON THE CHASSIS
64
F01533-10
–
Mount and tighten screw
1
.
Guideline
Remaining screws,
chassis
M6 10 Nm (7.4 lbf ft)
11.22 Removing the air filter box cover
Condition
The air filter box cover is secured.
– Remove the seat. ( p. 63)
F01588-10
–
Remove screw
1
.
F01588-11
–
Pull off the air filter box cover in area
A
sideways and
take off toward the front.
F01589-10
Condition
The air filter box cover is not secured.
–
Pull off the air filter box cover in area
A
sideways and
take off toward the front.
