KTM F8101S5 - Removing the Start Number Plate; Installing the Start Number Plate; Removing Front Fender

SERVICE WORK ON THE CHASSIS 11
59
11.14 Removing the start number plate
F01524-10
–
Remove screw
1
.
– Unhook the start number plate from the brake line and remove
it.
11.15 Installing the start number plate
F01525-10
–
Position the brake line in holders
A
on the start number
plate.
–
Position the start number plate. Mount and tighten screw
1
.
The holding lugs engage in the fender.
11.16 Removing front fender
Preparatory work
– Remove the start number plate. ( p. 59)
F01526-10
Main work
–
Remove screws
1
and
2
. Take off the front fender.
