22 TECHNICAL DATA
132
Ground clearance, unloaded 370 mm (14.57 in)
Weight without fuel, approx. (All SX‑F models) 99 kg (218 lb.)
Weight without fuel, approx. (XC‑F US) 100 kg (220 lb.)
Maximum permissible front axle load 145 kg (320 lb.)
Maximum permissible rear axle load 190 kg (419 lb.)
Maximum permissible overall weight 335 kg (739 lb.)
22.5 Electrical system
Battery HJTZ5S-FP-C Lithium-ion battery
Battery voltage: 12 V
Nominal capacity: 2.0 Ah
Maintenance-free
Fuse 58011109110 10 A
Malfunction indicator lamp LED
Remaining indicator lamps
(XC‑F US)
W2.3W / socket W2x4.6d 12 V
2.3 W
22.6 Tires
Validity Front tire Rear tire
(All SX‑F models) 80/100 - 21 51M TT
Dunlop GEOMAX MX3S F
110/90 - 19 62M TT
Dunlop GEOMAX MX3S
(XC‑F US) 90/90 - 21 54M TT
Dunlop GEOMAX AT81F
110/100 - 18 64M TT
Dunlop GEOMAX AT81
The tires specified represent one of the possible series production tires. Additional information is available in
the Service section under:
http://www.ktm.com
22.7 Fork
22.7.1 SX‑F EU
Fork article number 34.18.8S.05
Fork WP Suspension Upside down AER 48
Compression damping
Comfort 17 clicks
Standard 12 clicks
Sport 7 clicks
Rebound damping
Comfort 17 clicks
Standard 12 clicks
Sport 7 clicks
Air pressure 10.4 bar (151 psi)
Fork length 950 mm (37.4 in)
Oil capacity external mechanism
right
220
+ 20
− 40
ml (7.44
+ 0.68
− 1.35
fl. oz.) Fork oil (SAE 4) (48601166S1)
( p. 139)
Oil capacity external mechanism
left
220
+ 20
− 40
ml (7.44
+ 0.68
− 1.35
fl. oz.) Fork oil (SAE 4) (48601166S1)
( p. 139)
