24 TECHNICAL DATA
142
Screw, bottom triple clamp M8 18 Nm (13.3 lbf ft)
Screw, chain sliding piece M8 15 Nm (11.1 lbf ft)
Screw, fork stub M8 15 Nm (11.1 lbf ft)
Screw, front brake caliper M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, handlebar clamp M8 20 Nm (14.8 lbf ft)
Screw, rear brake caliper M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, rear engine sprocket cover M8 15 Nm (11.1 lbf ft)
Screw, side stand attachment M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, subframe M8 30 Nm (22.1 lbf ft)
Loctite
®
243™
Screw, top steering stem M8 17 Nm (12.5 lbf ft)
Loctite
®
243™
Screw, top triple clamp M8 22 Nm (16.2 lbf ft)
Screw, wheel speed sensor M8 4.5 Nm (3.32 lbf ft)
Shoulder bolt for attaching
Powerpack HV
M8 15 Nm (11.1 lbf ft)
Loctite
®
243™
Motor bracket screw M10 60 Nm (44.3 lbf ft)
Remaining nuts, chassis M10 45 Nm (33.2 lbf ft)
Remaining screws, chassis M10 45 Nm (33.2 lbf ft)
Screw, cross bar M10 45 Nm (33.2 lbf ft)
Screw, footrest bracket M10 45 Nm (33.2 lbf ft)
Loctite
®
243™
Screw, handlebar support M10 40 Nm (29.5 lbf ft)
Loctite
®
243™
Screw, motor guard M10 30 Nm (22.1 lbf ft)
Screw, subframe top M10 45 Nm (33.2 lbf ft)
Loctite
®
243™
Screw, bottom shock absorber M12 80 Nm (59 lbf ft)
Loctite
®
2701™
Screw, top shock absorber M12 80 Nm (59 lbf ft)
Loctite
®
2701™
Nut, swingarm pivot M14x1.5 75 Nm (55.3 lbf ft)
Nut, rear wheel spindle M20x1.5 80 Nm (59 lbf ft)
Screw, front wheel spindle M20x1.5 35 Nm (25.8 lbf ft)
Screw, top steering head M20x1.5 12 Nm (8.9 lbf ft)
