7 DISPLAY

26

7.2 Overview

7.2.1 Overview of indicator lamps

A00594-10

Possible states

The high beam indicator lamp lights up blue – The

high beam is switched on.

Turn signal indicator lamp flashes green – The turn

signal is switched on.
