SERVICE WORK ON THE CHASSIS 13
119
13.7 Mounting the front rider's seat
H01084-10
–
Attach recesses
1
on the front rider's seat to the fuel tank,
push the front rider's seat forward, and lower at the rear.
The pin
2
locks audibly in place.
– Check that the front rider's seat is mounted correctly.
13.8 Removing the passenger seat
Preparatory work
– Remove the front rider's seat. ( p. 118)
