KTM RC 390 2018 User Manual

CONTROLS 6
31
6.5 Light switch
K00706-11
The light switch
1
is fitted on the left side of the handlebar.
Possible states
Low beam on – Light switch is turned downward. In
this position, the low beam and tail light are switched
on.
High beam on – The light switch is turned upwards.
In this position, the low beam, the high beam and the
tail light are switched on.
6.6 High beam flasher button
K00697-11
The high beam flasher button
1
is fitted on the left side of the
handlebar.
Possible states
• High beam flasher button in neutral position
• High beam flasher button pressed – In this position, the
headlight flasher (high beam) is actuated.

KTM RC 390 2018 Specifications

General

Displacement	373.2 cc
Bore x Stroke	89 mm x 60 mm
Compression Ratio	12.6:1
Torque	36 Nm @ 7, 000 rpm
Transmission	6-speed
Cooling	Liquid cooled
Rear Suspension	WP monoshock
Front Tire	110/70 ZR17
Rear Tire	150/60 ZR17
Seat Height	820 mm
Ground Clearance	178.5 mm
Fuel Tank Capacity	10 liters
Dry Weight	147 kg
Engine Type	Single Cylinder, 4-Stroke
Power	43 hp (32 kW) @ 9, 000 rpm
Fuel System	Electronic Fuel Injection
Frame	Steel trellis frame
Front Suspension	WP upside-down Ø 43 mm
Front Brake	320 mm disc
Rear Brake	230 mm disc, single-piston caliper
ABS	Two-channel Bosch 9MB ABS
